Year: 2002
Stroke: 2
Cilinders: 1
Displacement: 49.7 cc
Bore and stroke: 40.3 x 39 mm
Compression: 12:1
Cooling: Liquid
Lubrication: Seperate, Automatic
Carburetor: Dell'Orto PHBN12 - HS
Ignition: CDI
Gears: 6
Front suspension: telehydraulic fork, travel 110 mm
Rear suspension: hydraulic monoshock, travel 110 mm
Front brake: Disc, 280 mm
Rear brake: Disc 220 mm
Front tire: 90/80 x 17
Rear tire: 110/80 x 17
Wheelbase: 1280 mm
Seat height: 89 Kg
Starter: Electric
Fueltank capacity: 12.2
Estimated price: 2950,- Euro's
Stroke: 2
Cilinders: 1
Displacement: 49.9 cc
Bore and stroke: 39.8 x 40.0 mm
Cooling: Liquid
Lubrication: Seperate, automatic
Horsepower: 9 HP
Kilowatts: 6.6 KW
Carburetor: Dell'Orto PHVA 17
Ignition: CDI
Gears: 6
Dry weight: 85 KG
Starter: Electric
Fueltank capacity: 7.25
Estimated price: 2700,- Euro's
Year: 1992
Stroke: 2
Cilinders: 1
Displacement: 49,93 cc
Bore and stroke: 39 x 41,8 mm
Cooling: Liquid
Carburetor: Dell'orto 14/12
Front brake: 270 mm
Rear brake: 240 mm
Front tire: 90-16
Rear tire: 110-17
Dry weight: 87 Kg
Fueltank capacity: 13 L
Top speed: 100 Km/h
Stroke: 2
Cilinders: 1
Displacement: 49 cc
Bore and stroke: 39 x 41.1 mm
Cooling: Air
Lubrication: Seperate, Automatic
Horsepower: 7 HP
Carburetor: Keihin 16.6
Ignition: CDI
Gears: 5
Front brake: Disc
Rear brake: Drum
Front tire: 2.75 - 18
Rear tire: 3.00 - 18
Dry weight: 78 Kg
Starter: Kickstart
Fueltank capacity: 9 L
Stroke: 2
Engine: AC08E
Cilinders: 1
Cooling: Air
Lubrication: Seperate, Automatic
Carburetor: PF70
Ignition: CDI
Gears: 6
Starter: Kickstart
Fueltank capacity: 10,2
Stroke: 2
Engine: AC08E
Cilinders: 1
Displacement: 49 cc
Bore and stroke: 39mm x 41.4mm
Cooling: Liquid
Stroke: 2
Engine: AC08E
Cilinders: 1
Displacement: 49 cc
Bore and stroke: 39,0 x 41,1 mm
Cooling: Liquid
Lubrication: Seperate, automatic
Horsepower: 7.2 @ 10.000 rpm
Carburetor: Keihin PF72
Ignition: CDI
Gears: 6
Front tire: 90/80 - 17
Rear tire: 100/80 - 17
Stroke: 2
Cilinders: 1
Displacement: 49,9 cc
Bore and stroke: 40,0 x 39,8
Cooling: Liquid
Gears: 6
Front tire: 90-16
Rear tire: 120-16
Dry weight: 89 Kg
Fueltank capacity:
Stroke: 2
Engine: AC08E
Cilinders: 1
Displacement: 49 cc
Bore and stroke: 39mm x 41.4mm
Cooling: Liquid
Lubrication: Seperate, automatic
Ignition: CDI
Gears: 6
Sprockets: 14 -4
Front tire: 2.75 x 17
Rear tire: 3.00 x 17
Dry weight: 90 Kg
Fueltank capacity: 10 L
Top speed: 105 km/h
Year: 2002
Stroke: 2
Engine: AC08E
Cilinders: 1
Displacement: 49 cc
Bore and stroke: 39 x 41,4 mm
Cooling: Liquid
Lubrication: Seperate, automatic
Horsepower: 7,2 @ 10.000 rpm
Torque Nm: 6.4 @ 7,500 rpm
Carburetor: PF70
Ignition: CDI
Gears: 6
Front tire: 90/80 x 17
Rear tire: 90/80 x 17
Wheelbase: 1,260 mm
Dry weight: 75 Kg
Stroke: 2
Engine: AC08E
Cilinders: 1
Displacement: 49,0 cc
Bore and stroke: 39 x 41.4 mm
Cooling: Liquid
Lubrication: Seperate, Automatic
Horsepower: 7.2 @ 10.000 rpm
Carburetor: Keihin HM 16.6
Ignition: CDI
Gears: 6
Front tire: 2.75 x 17 Inch
Rear tire: 3.00 x 18 Inch
Dry weight: 92 Kg
Fueltank capacity: 10.2
Top speed: 110 km/h
Estimated price: 2260,- Euro's
Stroke: 2
Engine: AC08E
Cilinders: 1
Displacement: 49cc
Cooling: Liquid
Lubrication: Seperate, Automatic
Carburetor: Keihin
Ignition: CDI
Gears: 6
Front tire: 100 - 12
Rear tire: 120 - 12
Dry weight: 83 Kg
Starter: Kickstart
Fueltank capacity: 7.5 L
Stroke: 2
Cilinders: 1
Displacement: 49 cc
Bore and stroke: 39.0 x 41.6 mm
Cooling: Air
Horsepower: 7,2 HP @ 9,000 rpm
Gears: 6
Dry weight: 78 KG
Fueltank capacity: 9,6 L
Stroke: 2
Cilinders: 1
Cooling: Liquid
Lubrication: Seperate, Automatic
Carburetor: DellLorto SHA 14 9
Ignition: Electronic
Stroke: 2
Engine: Moto Minarelli
Cilinders: 1
Displacement: 49,7 cc
Bore and stroke: 40.3 x 39.0
Cooling: Liquid
Gears: 6
Front suspension: howa USD telescopic forks
Front brake: 260 mm
Rear brake: 220 mm
Front tire: 90/90 16
Rear tire: 120/80 16
Dry weight: 85 Kg
Fueltank capacity: 11,75
Estimated price: 2675,- Euro's
Stroke: 2
Cilinders: 1
Displacement: 49,9 cc
Bore and stroke: 39 x 40.3 mm
Cooling: Liquid
Lubrication: Seperate, Automatic
Horsepower: 8 HP
Kilowatts: 5.8 KW
Ignition: CDI
Gears: 6
Front tire: 90 - 16
Rear tire: 120 - 16
Fueltank capacity: 9 L
Year: 2003
Stroke: 2
Engine: Minarelli AM-6
Cilinders: 1
Displacement: 49cc
Bore and stroke: 39 x 40.3 mm
Compression: 12:1
Cooling: Liquid
Lubrication: Seperate, Automatic
Carburetor: Dellorto PHBN 14-12
Ignition: CDI
Gears: 6
Front suspension: Upside down hydraulic fork 35mm
Rear suspension: Mono shock absorber
Front brake: Disc 280mm
Rear brake: Disc 220mm
Front tire: 90/80 - 17
Rear tire: 110/80 - 17
Starter: Electric
Fueltank capacity: 10 L
Oiltank capacity: 1.5 L
Estimated price: 3600,- Euro's
